YKF-XZS 125CC Youth ATV | Mini Four Wheeler for Sale

This mini quad bike, the YKF-XZS, is a value-focused 125cc youth ATV for distributors who need a reliable entry-level model. Powered by a 4-stroke air-cooled engine with automatic clutch and chain drive, it reaches 45 km/h with a 670 mm seat height and a tidy 1450x920x950 mm body at 100 kg. Straightforward specifications and consistent build quality make this mini quad bike one of the most exportable 125cc kids quads in the YKF lineup.

Colors

Engine Type125CC, 4-Stroke, Air Cool, Single cylinder
TransmissionChain Drive
Max Speed (km/h)45 km/h
Seat Height (mm)670mm
Dimensions And Weight1450x920x950mm 100kg
SKU: YKF-XZS Category:

$658.00

10 pieces.

Quantity Price Discount
1-10 $658.00 0%
11-50 $608.00 $50.00
51+ $558.00 $100.00
Secure B2B Order Process

Orders are confirmed by quotation and Proforma Invoice. T/T, L/C for qualified bulk orders, and Alibaba trade assurance are available upon request.

Pre-Shipment Quality Check

Each vehicle is inspected before shipment. Photos, videos, packing details, commercial invoice, and packing list can be provided.

Technical Specification
Engine Type
125CC, 4-Stroke, Air Cool, Single cylinder
Max Power (kW/rpm)
5.3kW/7500rpm
Max Torque (N.m/rpm)
8.0N.m/5500rpm
Bore*Stroke (mm)
52.4x55.5mm
Compression Ratio
9.0:1
Clutch
Automatic Clutch
Start Mode
Electric Start
Driving Type
2WD
Transmission
Chain Drive
Brake System
Front Disc + Rear Disc
Tire Size
19x7-8 / 18x9.5-8
Rim Type
Steel Rim
Max Speed (km/h)
45 km/h
Battery
12V 5AH
Wheelbase (mm)
1015mm
Ground Clearance (mm)
120mm
Seat Height (mm)
670mm
Dimensions And Weight
1450x920x950mm 100kg
Color
Grey, Black, Blue, Yellow, Green, Orange, Red
Package Size And Weight
1310x810x730mm 110kg
Quality Inspection
    Sourcing
  1. 01AP

    Accessories Purchase

    Vetted-supplier sourcing of frames, engines, drivetrain & electricals with full traceability.

  2. 02IQC

    Incoming Quality Control

    AQL sampling on every inbound lot; non-conforming parts rejected and returned.

  3. Production
  4. 03PA

    Product Assembly

    Torque-controlled assembly lines with station-level checklists for ATV, UTV, dirt & pit bikes.

  5. 04PQC

    Process Quality Control

    In-line inspection at critical stations; defects routed back to assembly for rework.

  6. 05FP

    Finished Product

    Engine run-in, brake, lighting, throttle and road-test verification on each unit.

  7. 06OQC

    Outgoing Quality Control

    Pre-shipment AQL audit per ANSI/ASQ Z1.4; any failure loops back to assembly.

  8. Dispatch
  9. 07FW

    Finished Goods Warehousing

    Climate-controlled storage, serialized bin locations and FIFO dispatch queue.

  10. 08PS

    Packing & Shipping

    Export-grade crating, fumigation, container loading plans and BL documentation.

Closed-loop rework

When PQC or OQC detects a non-conformity, the affected unit is routed back to Product Assembly with a traceable defect ticket. Nothing moves forward until it passes — zero-escape to our customers.
